Very Narrow Aisle Racking

Very Narrow Aisle Racking (VNA) is especially designed to allow very efficient use of your floor space and your height space, helping you increase the capacity of the warehouse without having to expand the floor space.



Request a QuoteONLINE DESIGN TOOL

Features


Aisle Width

1.6 metres

Space

45% Space Utilisation

Access

100% Accessibility

Throughput

High Throughput Speeds

Forklift

Specialist Forklift Options

What is Very Narrow Aisle Racking?

Very Narrow aisle racking (VNA) is generally used in warehouses that are a little tighter on space. A reduced aisle width of approximately 1.8 meters means floor space is much better utilized increasing it to 45%.

Using a narrow aisle Forklift truck allows you to access all pallets, lifting higher and working faster than standard counterbalance trucks.

As trucks such as these do not turn in the aisles, they need a guide rail or wire guidance system. This allows them to manoeuvre around the racking with a high degree of accuracy.

The advantage of using wire guidance is that is it built within the floor which keeps it clear of obstructions and makes it easier to clean. Each pallet is easily accessible and this ensures good stock rotation and accessibility.

Advantages of this system

  • Enables high-density storage utilizing floor area and roof height
  • Store pallets close together by reducing aisle widths up to 50% and store high
  • 100% accessibility to every pallet stored with narrow aisle trucks
  • Damage rate reduction, narrow aisle trucks are often guided by wire or rail
Contact Us

Pallet Racking Systems

Adjustable Pallet Racking

This is the most common form of pallet racking. APR is a system of beams clipped into frames.

In general the beams support the pallet but on occasions the pallet is also supported by timber decking, mesh decking or pallet support bars.

find out more

Very Narrow Aisle Racking

Very Narrow Aisle Racking is generally used in warehouses which are a little tighter on space.

Using a narrow aisle Forklift truck allows you to access all pallets, lifting higher and working faster than standard counterbalance trucks.

find out more

Drive-in Racking

Drive-in Racking is an ideal system for large quantities of the same type of product. It is a variation to block stacking.

It works on the principle of first in last out so is not particularly good for stock rotation.

find out more

Push Back Racking

Push Back Racking systems are designed around the principle of organising space by depth rather than width.

This depth arrangement greatly reduces aisle space and increases storage density.

find out more

Shuttle Racking

Shuttle Racking is an alternative to Drive In racking or Live Storage Racking.

The idea is that each lane is a single product but unlike drive in racking not all products within the bay need to be the same thus allowing greater density of storage.

find out more

Live Storage Racking

Live Storage Racking is a system where pallets are put onto rollers at one end and they can then run down the rollers to be picked off at the other end.

It is a relatively expensive storage solution but can improve efficiency in many warehouses.

find out more

Mobile Pallet Racking

The Mobile Pallet Racking consist of units of conventional pallet racking mounted on a steel framed base.

This system is installed over guided mobile bases that slide laterally, eliminating the need for aisles.

find out more

Special Racking

Carpets, carpet pads and rolls of vinyl are inefficiently stored on pallets, which is why carpet racks are a much better storage alternative to maximize your valuable floor space. A system that is good for storing rolled up lengths of material such as carpet.

find out more
